Haul-off machine (Left double line)
Haul-off machine (Left double line)
TN-48Q L2-02

Haul-off machine (Left double line)

TN-48Q R2-02

Haul-off machine (Right double line)
  •  Pre-stage control
  •  Yarn guide path

TN48_PDF.pdf

Advantage
  • Pre-stage control: The haul-off & feeding speed of extruder is controlled by frequency conversion vector.
  • Yarn guide path: stainless steel scratch-resistant chrome-plated take-up wheel.

Feature
  • Speed control: motor speed controlled by inverter.
  • Yarn break deceleration: hen single yarn breaks, slow down speed automatically.
  • Emergency protection: E-STOP emergency control switch.

ModelTN48Q L2-01TN48Q R2-01TN48Q L2-02TN48Q R2-02
Take-up speed30-800m/min
Motor1HP×2
Safety scroll wheel(W/O)1/2HP×1 (1:15)
Packing measuremant90L×100W×170H (cm)110L×100W×170H (cm)
Machine WeightN.W.:320KGS   G.W.:400KGSN.W.:335KGS   G.W.:430KGS

All specifications and designs subject to change without notice.


Optional
  • Safety Scroll Wheel 50～60m/min
  • Safety cover
