TN48A X2-01

Automatic bobbin changing winder (Double line)

Suitable for winding: multifilaments, high performance fibers, covered fibers , coated fibers & twisted yarns.

Automatic spindle change system:
- Automatic spindle change when reaching to presetting length. (Above function is only for model 48A.)
Servo winding system: precision yarn laying, stable tension and low power consumption.
Digital parameter setting: parameter digitized, stable production quality.
Production program: 50 sets of program modules easy to select production specifications.
Pre-stage follow: winding speed is stable corresponding with yarn haul-off speed(30-800m/min).
Suitable for winding: mutifilaments, high performance fibers, covered fibers , coated fibers & twisted yarns.

Operation panel: 7 inches HMI, clear operation.
Package hardness: adjustable arm pressure, to reduce pressure marks and make package softer. Uniform hardness inside and outside.
Tension: adjustable air pressure tension pole.
Yarn breakage detector: when one yarn breaks the other yarn can continue high-speed production.
Cross ratio: can set the number and density of different patterns in the inner layer.
Info feedback: alarm and buzzers when yarn breaks or abnormal operation.
Finished product take-out: automatic when product finished or press the button.

All specifications and designs subject to change without notice.

Optional: Safety cover
